MXD Series DIP-Switch Temperature Controller

The MXD Series is a compact, panel-mount temperature controller that brings precision and simplicity to industrial and commercial thermal applications. Designed for fast, error-free setup, it features thumbwheel digital setting with 0.5% accuracy, eliminating complex menu navigation.

Users can freely switch between ON/OFF and PID control modes via a front-panel toggle, with built-in LED indicators for real-time status monitoring. The controller delivers reliable performance with a 100ms sampling rate, 2,000VAC isolation, and robust heat tolerance, ensuring stable operation in demanding environments.

Ideal for heat-sealing machines, shrink-packaging equipment, injection molding, HVAC systems, food processing, medical devices, and laboratory research, the MXD Series offers industrial-grade durability in a user-friendly package – where precision meets simplicity.

The MW30L series is a compact, high-performance three-phase SCR power regulator designed for precise control of electrical heating systems. With a current range from 25A to 350A, it is highly suitable for both resistive and inductive loads in various industrial applications.

1.Current rating options from 25A up to 350A to meet diverse industrial heating requirements.
2.Comprehensive universal analog input support including 0-5V, 0-10V, 0-20mA, and 4-20mA, along with 2 digital inputs and 1 digital output.
3.Flexible trigger modes featuring both phase angle firing and zero-cross firing control.
4.Advanced built-in protection functions including phase loss, overcurrent, overheating, overload, and load disconnection.
5.Standard RS-485 communication interface utilizing the Modbus-RTU protocol for seamless system integration.
6.Multiple control modes available: Constant Voltage (V), Constant Current (I), Constant Power (P), and Open-loop control.
7.Optional expansion modules available for temperature function and external display panel.

The MW30E series is an advanced, three-phase power regulator (current range: 25–1500A), Suitable for both resistive and inductive loads

1. Rating from 25A all the way up to 1500A
2. 0-5V/0-10V/0-20mA/4-20mA analog input, 3 digital inputs, 1 digital output, Modbus-RTU
3. Phase angle firing control mode or burst-firing mode configurable
4. Work with load on Star, Delta or Star with netural wire
5. Modbus RS-485 available as default,  other communication like profibus DP, Ethernet can be custom made
6. Different control mode, Constant Voltage (V) / Constant Current (I) / Constant Power (P)/Open-loop
7.100% load can be applied to the SCR according to the rating, for example, 100 amps rating SCR, you can apply 100 amps to phase current. there is no need to take the derating into consideration

• PT100-1 is a screw-in type PT100 with a screw at the head, the screw can be M6, M8, 1/4 BSP, or other special screws
• PT100 or PT1000 Classs A, Class AA, or Class B accuracy
• Lead wire can be PVC wire, Silicone wire, PTFE/FEP wire or Fibreglass braided wire

• The connection can be fork connector, stripped wire or M12 quick connector

• Sensors can be made with 2 wires, 3 wires and 4 wires.

Cost effective PID Temperature controller, available with all major sizes, Relay+SSR Drive output as standard options. Other outputs such as 4-20mA and 0-10Vdc also available. TC/RTD inputs , Relay and SSR Drive output are two of most demanding outputs, this feature makes this controller accomendate to most of applications

This is a 1/16 DIN 48mm*48mm powerful temperature controller, controller works with universal input, TC/RTD/Analog, it’s a true universal input controller, equipped with Relay and SSR Drive output which are two of most popular output, with the universal input and selectable output, this controller is accommodated to most of application,  Carry 3 years warranty and with a signature white and green display, fully sealed housing, anti-corrosion, anti-dust and waterproof, fast sampling rate, this is a best choice for distributor and end

4 digits Temperature controller, Universal input(TC/RTD), relay and SSR drive output field selectable. various size available, AC source or DC source optional.
parameter reset function to help you go back to factory default.

FS08 series controller is LCD display digital PID controller, vivid LCD display for easy to read from distance, True universal input, works with TC/RTD and analog input, relay and SSR Drive output field selectable makes it suitable for most of industrial application, comes with different size, 48mm*48mm, 72mm*72mm, 96mm*96mm, 48mm*96mm, a lot of add-on features like auto/manual control switch, parameter resets to factory default, RS-485 optional, customized parameter layout, makes this a competitive cost-effective PID controllers on the markets

This is a PID temperature controller works with universal signal, thermocouple, RTD and analog signals, comes with several options on the output, popular choices is Relay, SSR Drive and 4-20mA, 0-10VDC output, fast sampling rate and built-in timers optional, for system intergration purpose, you can choose the RS-485 modbus feature, up to 2 alarms, heating and cooling control configurable, vivid LCD display. offers standard PID control mode and ON/OFF control mode. fuzzy logic pid algorithm

The Maxwell PT100-2 Series is a versatile and robust probe-type Resistance Temperature Detector (RTD) designed for precise and reliable temperature measurement across a wide range of industrial applications. This series offers exceptional flexibility with customizable probe diameters, lengths, and compensation lead wires, ensuring seamless integration into diverse systems. Engineered for durability, the PT100-2 series can also be configured with a waterproof design, making it suitable for challenging environments. With its high accuracy and customizable features, the PT100-2 series provides an ideal solution for demanding temperature sensing requirements.

Simple but accurate 3 digits display, for application less than 1000 degree C or F, Thermocouple and RTD input to accommodate most of applications, touch button which do not wear out over time, perfect for demanding situation, advanced control algorithm to achieve perfect control accuracy with limited overshoot and undershoot, 3 years warranty, relay and SSR Drive output on the same device, large and high visibility LED display, two options on the display, white+green or red +yellow, Simple and easy to use is the concept of this controller, very limited parameters to reduce the workload on configuration. CE and ROHS compliant.

MTD series PID temperature controller is a cost effective pid controller offers basic features that will suit a lot of basic temperature control needs, works with TC/RTD inputs, and equipped with Relay and SSR drive output at the same time, the output is field selectable, if the actuator is a conventional relay or AC contractor, then choose the relay output, if the system has a solid state relay, then choose the SSR drive output, it's a great choice to have, maximum 2 alarms, working on wide power source from 85~265VAC or 24VDC. RS-485 modbus is avaiable on request.

The PT100-3 is a widely used probe-type Platinum Resistance Thermometer (PT100 RTD) engineered for reliable and accurate temperature measurement in harsh industrial environments. The sensor integrates a rugged Form B connection box that protects internal wiring from dust, moisture, and mechanical damage, making it especially well suited for outdoor installations, chemical plants, and other demanding process environments.

Compliant with EN 60751, the PT100-3 delivers a broad measurement range of −70 °C to +300 °C with high stability and repeatability. The sensor is compatible with a variety of standard process fittings — including 1/2 NPT, 1/2 BSP, 3/4 NPT, and M16 — enabling straightforward integration into existing pipelines and equipment. Probe diameter and length are fully customisable, allowing the PT100-3 to be tailored to virtually any installation requirement.

Robust and versatile temperature controller, carry 3 years warranty.modular design, customer can install the modular according to customer's requirements. touch key design, the setting button is touch key, robust and long lasting. true universal input, works with TC/RTD and analong input, Various output such as relay, SSR Drive, 4-20mA, 0-10V,  250 ms sampling rate, IP67 possible with water tight gasket installed, super lower comsumption, very small temperature drift, high visible LED display, available with different color options, white/green or red/yellow.

MTA series PID temperature controller is a programmable pid temperature controller offers solutions for most of application, this controller works with Thermocouple, RTD(PT100) and Analog signal like 0-10VDC, 4-20mA etc, it's a true universal input controller which works with all inputs, Relay, SSR Drive output and analog outputs are optional upon order, add-on features like RS-485 and Process re-transmission is avaiable on request. Compatible with wide range of power source from 85~265Vac.

Robust and versatile DIN rail mount temperature controller, carry 3 years warranty. touch button with responsive beep sound. Universal TC/RTD/Analong input
