MF43H is a touch screen ramp and soak controller, the conventional ramp and soak controllers or some call it profile controllers on the markets are configured via set buttons on the front panel. end user have to go through layers upon layers of parmaeters and navigate through different parameter during the configuration process. the process could be painful and stressed and often times lead to less efficient and frustration. the configuration with our touch screen ramp and soak controller is much more easier, it's easier for end user to pick up the process as they operate the controller like a cell phone. below are some of the basic features with this touch screen ramp and soak profile controller

FS08 series controller is LCD display digital PID controller, vivid LCD display for easy to read from distance, True universal input, works with TC/RTD and analog input, relay and SSR Drive output field selectable makes it suitable for most of industrial application, comes with different size, 48mm*48mm, 72mm*72mm, 96mm*96mm, 48mm*96mm, a lot of add-on features like auto/manual control switch, parameter resets to factory default, RS-485 optional, customized parameter layout, makes this a competitive cost-effective PID controllers on the markets

This is a PID temperature controller works with universal signal, thermocouple, RTD and analog signals, comes with several options on the output, popular choices is Relay, SSR Drive and 4-20mA, 0-10VDC output, fast sampling rate and built-in timers optional, for system intergration purpose, you can choose the RS-485 modbus feature, up to 2 alarms, heating and cooling control configurable, vivid LCD display. offers standard PID control mode and ON/OFF control mode. fuzzy logic pid algorithm

MLC series PID temperature controller is a low cost robust pid controller offers basic features that will suit a lot of basic temperature control needs, works with thermocouple(K,E,J,N,T,S,R,B) and RTD(PT100,Cu50) inputs, controller comes with Relay and SSR Drive output at the same time, you can select the output based on the field application, maximum 2 alarms and works with main source 85~265Vac or 24VDC. the housing is made of fire resistance material and front panel with soft setting buttons

MTD series PID temperature controller is a cost effective pid controller offers basic features that will suit a lot of basic temperature control needs, works with TC/RTD inputs, and equipped with Relay and SSR drive output at the same time, the output is field selectable, if the actuator is a conventional relay or AC contractor, then choose the relay output, if the system has a solid state relay, then choose the SSR drive output, it's a great choice to have, maximum 2 alarms, working on wide power source from 85~265VAC or 24VDC. RS-485 modbus is avaiable on request.

MTA series PID temperature controller is a programmable pid temperature controller offers solutions for most of application, this controller works with Thermocouple, RTD(PT100) and Analog signal like 0-10VDC, 4-20mA etc, it's a true universal input controller which works with all inputs, Relay, SSR Drive output and analog outputs are optional upon order, add-on features like RS-485 and Process re-transmission is avaiable on request. Compatible with wide range of power source from 85~265Vac.

FT series PID temperature controller is similar to other controllers we have but offers more options, items works with thermocouple and RTD inputs, comes with Relay, SSR Drive, or 4-20mA, 0-10VDC output, maximum 2 alarms avaiablel, standard version works on 85~265Vac, and 24VDC/AC source optional when order, apart from these standard features, this controller also has some unique features like soft-start for analog output which is pretty useful for some of application where the load needs to be protected from drastic increase power load, process value re-transmission and remote setting point, RS-485 modbus communication which makes this controller has the ability to handle different situations.

REX C100, C400, C700, C900 is a very popular controller on the markets, comes with relay or SSR Drive output, with 1 alarm and works on wide range of power supply, works with thermocuple and RTD inputs despite the cost being very competetive.

CH102, CH402, CH702, CH902 is a very popular controller on the markets, comes with relay and SSR Drive output, relay and SSR Drive output at the same time, faciliated wiht different terminals, if you want to use the relay output, then connect your AC contractor or SSR with the relay output terminal, if you want to use SSR drive output, then connect your solid state relay with SSR Drive output terminal, with 1 alarm and works on wide range of power supply, works with thermocuple and RTD inputs despite the cost being very competetive.

Maxwell DR02B is a din rail mount PID temperature controller, 2 channel configuraitons, support thermocouple inputs(K,E,J,N,W,S,T,R,B), and output can be Relay, SSR Drive, it's a very simple din rail mount ccontroller, PID or ON/OFF control mode, RS-485 modbus communication as standard features, 85~265Vac source for easy system intergration, auto-tuning for both loops and with an external plug and play external configruation devices. the field configuration will be very easy to carry out.

Maxwell PU90 ramp and soak PID profile multile steps controller is a touch key temperature controller, the process value changed based on predetermined ramping rate and soak rate. process value changes based on a curve over time, the output can be Relay to drive an AC contrator, or SSR Drive to drive an external solid state relay, or 4-20mA analog outputs, the setting keys on the panel is touch key with a responsive sound, it is not a conventional setting key where it goes down a little bit when you push it, it's a touch key which makes it very durable. high sampling rate and RS-485 optional.
